Aluminium Hand Winch Lifting Stacker with Straddle Legs

Product Item：BR-159, BR-181, BR-227

Max. Lifting height 3000mm, 2500mm and 1200mm

Min. Fork height 50mm

Fork length 570mm

Max. Overall forks width 630mm

Straddle Legs Aluminium Hand Winch Lifting Stacker

BR series

■ Overall straddle legs width 1100mm.

■ The min. fork height is only 50mm, which can touch the floor.

■ Forks down for lifting goods, forks up for supporting.

■ Easy disassembling and assembling.

■ Can fit into smaller space when disassembled.

■ Equipped with wheels on the mast also allow it to be used as a trolley.

■ Light aluminium mast, easy for handling.

■ Lift by winch, no any oil leakage risk.

■ The best brake function with special design.

■ Option platform is available.
