Manual Hydraulic Scissor Lift Pallet Trucks High Lift Pallet Jacks

Description

Manual Hydraulic Scissor Lift Pallet Trucks High Lift Pallet Jacks
HC-M series

■ Scissor lift pallet truck design to load and unload conveyor, feed presses, or any applications requiring moving and positioning pallets or containers of materials.

■ With presssure relief valve and overload valve to prevent pump damages when loads exceeds weight limits.

■ The enclosed fork tips and reinforced fork frames ensures long service life.

■ Equped with polyurethane loading roller and steering wheels to protect your floor.

■ The truck will be braked automatically when lift to the maximum height.

■ Double-stage cylinder makes the lower peak, more compact.

■ Combination as hand pallet truck and lift table.

■ Automatic descending speed control by a uniquely hydraulic value, the descending speed keeps same with or without load.

■ No decrease of capacity.

■ No risk of leakage.

■ Conforms to EN1757-4.

Model		HL1054M	HL1068M	HL1554M	HL1568M
Capacity	(kg)	1000		1500
Max. Fork Height	(mm)	800
Min. Fork Height	(mm)	85
Fork Length	(mm)	1150		1130
Overall Forks Width	(mm)	540	680	540	680
Fork Roller Size	(mm)	Ø80x70
Steering wheel Size	(mm)	Ø180x50
Net Weight	(kg)	110	125	120	130
